CNC Machining Projects
I’m passionate about machining and skilled in programming and operating CNC mills, lathes, and routers. From generating CAM and G-code files from CAD models to manual and CNC machining, I’ve worked with metals, wood, and plastics. Explore my CNC projects below.
Machines and software I have used:
CAD/CAM packages: Solidworks with MasterCAM, Fusion360, Vectric
CNC Machines: Hass Mini mill, Hass TL-1 CNC Lathe, Genmitsu CNC router, Forest Scientific CNC Router, various manual lathes and mills
CNC Machined Chess board
CAD/CAM: Solid works, MasterCAM
Machines: Hass Minimill, manual mill, bandsaws, polishing wheels
Draft Analysis
FIDGET Spinner
My friend Jonathan and I made around 30 pairs and gave them to our friends.
1 year later I fabricated a pair out of walnut wood, using a CNC router. This time the CAM was made on Fusion360.
Other Wood CNC Projects…
Finished Frames
Draft Analysis was done on Solidworks. A draft of 1.5 degrees was added for easy ejection of parts from the mold
Draft Analysis
CAD/CAM: Solid works, MasterCAM
Machines: Hass Minimill, manual mill, power tools, morgan press
Project type: Class project, team of two.
Toolpath for machining the mold halves on the Hass mini mill was developed using MasterCAM. The operation on each half of the mold, including two tool changes was done in approximately in 45 mins.
Plastic Flow Simulation
Machined Mold Halves
Party Frames: Injection Molded frames and CNC machined molds
Steps:
Design CAD of the part favorable for injection molding
Design and machine the mold favorable for machining.
Injection mold the parts.
Millenium Falcon (Left)
Terrace Dreams (Right)
These were done on my Desktop CNC router.
I made the toolpaths on Fusion360 and used OpenBuildsCONTROLS to run the CAM.
Freshly Injected Product
The Hall of Frame
The Buddha
This was my first 3D wood CNC project. I downloaded the CAD file and made my CAM/toolpaths
